Camera

Resolution: 3K Resolution

Image Sensor: 1/3" Progressive Scan CMOS

Shutter Speed : Self-adaptive shutter

Lens: 4mm@F1.6, view angle: 105°(Diagonal), 88° (Horizontal), 46°(Vertical)

Lens Mount: M12

Day & Night: IR-cut filter with auto-switching

DNR: 3D DNR

WDR: WDR

Compression

Video Compression: H.264/H.265

Video Bit Rate : Adaptive bit rate.


Max. Resolution: 3K (2880 × 1620)

Frame Rate: Self-Adaptive during network transmission

Network

Smart Alarm: Motion Detection, AI-Powered Human Shape Detection

Wi-Fi Pairing: AP paring

Protocol: EZVIZ cloud proprietary protocol

Interface Protocol: EZVIZ cloud proprietary protocol

Interface

Storage: Micro SD card slot (Max. 512G)

Power: TYPE-C

Wired Network: RJ45 X 1 (10M/100M self-adaptive Ethernet port)

Wi-Fi

Standard: IEEE802.11a, 802.11b, 802.11g, 802.11n

Frequency Range: 2.4 GHz: 2.4 GHz ~ 2.4835 GHz

Channel Bandwidth: 2.4G: Supports 20 MHz

Security: WPA/WPA2, WPA-PSK/WPA2-PSK

Transmission Rate: 11b 11Mbps, 11g 54Mbps, 11n MCS7, 11a 54Mbps, 11ac MCS9.11ax MCS11

Output Power(EIRP): 19 dBm

Antenna Gain: 1.9 dBi

General

Operating Conditions: -10°C to 45°C (14°F to 113 °F ), Humidity 95% or less (non-condensing)

Power Supply: DC 5V/2A

Power Consumption: 8W max

IR Range: MAX. 10 meters(32.81ft)

Dimensions: 88mm x 88.2 mm x 119mm (3.46[?] x 3.47[?] x 4.69[?])

Packaging Dimensions: 103mm x 103mm x 168mm (4.06[?] x 4.06[?] x 6.61[?])

Bare Weight: 222 g (0.49 lb)

In the box

- Camera

- Power Adapter

- Power Cable

- Drill Template

- Mounting Plate

- EZVIZ Screw Kit

- Regulatory Information

- Quick Start Guide
