HARDWARE FEATURES
Interface Fast Ethernet (RJ-45) Port *1?Support Passive PoE?
Button Reset
Power Supply 24VDC / 0.6A Passive PoE Supply
Power Consumption 6.3 W
Dimensions ( W x D x H ) 8.2 × 3.7 × 1.7 in. (209 × 95 × 42.6 mm)
Antenna Type 2*5dBi External Omni waterproof
Weatherproof Enclosure IP65
Mounting Pole / Wall Mounting (Kits included)
Watch Dog Yes
WIRELESS FEATURES
Wireless Standards IEEE 802.11n/g/b
Frequency 2.4GHz
Signal Rate 11n: Up to 300Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)
Transmit Power CE?
<20dBm
FCC:
<27dBm
Wireless Functions Multiple SSIDs?Up to 8 SSIDs?
Enable/Disable Wireless Radio
Automatic Channel Assignment
Transmit Power Control ?Adjust Transmit Power on dBm?
QoS(WMM)
Load Balance
Rate Limit
Reboot Schedule
Wireless Schedule
Wireless Statistics based on SSID/AP/Client
Wireless Security Captive Portal Authentication
Access Control
Wireless Mac Address Filtering
Wireless Isolation Between Clients
SSID to VLAN Mapping
Rogue AP Detection
802.1X Support
64/128/152-bit WEP / WPA / WPA2-Enterprise,
WPA-PSK / WPA2-PSK
MANAGEMENT
Omada App Yes
Auranet Controller Software Yes
Centralized Management [?] Omada Cloud-Based Controller
[?] Omada Hardware Controller (OC300)
[?] Omada Hardware Controller (OC200)
[?] Omada Software Controller
Cloud Access Yes (Through OC300, OC200, Omada Cloud-Based Controller, or Omada Software Controller)
